Steel vs LVL Beams: Which is Right for Your Project?
When removing a load-bearing wall, you need a beam to support the load. But should you choose steel or LVL (Laminated Veneer Lumber)? This guide explains the differences.
As structural remodeling experts, we work with licensed engineers to guide GTA homeowners through this choice every day. The right answer depends on your span length, ceiling height requirements, and budget.
Understanding Your Beam Options
Steel W-Beams
The industry standard for structural support. W-beams (wide-flange) have an "I" shape that efficiently resists bending. They are strong enough to span large distances while remaining shallow enough to hide inside a ceiling.
LVL Beams
Engineered wood product made from laminated wood veneers. Designed for consistent strength and stability. LVL is cost-effective for shorter spans and easier to install without heavy equipment.
At a Glance: Head-to-Head Comparison
| Factor | Steel W-Beam | LVL Beam |
|---|---|---|
| Max Span | 30+ feet | 14–16 feet |
| Cost | Higher | Lower |
| Flush Install | Yes | Usually no |
| Fire Resistance | Excellent | Poor |
| Moisture | Impervious | Vulnerable |
| Weight | Heavy | Lighter |
| Installation | Equipment needed | Easier |
01. When to Choose Steel
Our Recommendation:For most GTA open-concept projects over 14 feet, steel is the better choice despite higher upfront cost.
Choose steel beams when:
- Span exceeds 14 feet
- You want a flush (hidden) ceiling
- Supporting a second floor or roof
- Fire resistance is important
- Long-term durability is the priority
- Maximum strength is needed
The Flush Beam Advantage
Most Toronto homeowners want a "flush beam" installation — where the new beam is tucked inside the ceiling joists so the ceiling is flat all the way across.
Since standard floor joists are often only 8 to 10 inches deep (especially in older homes), you need a beam that fits within that height. Only steel is strong enough to span large distances while remaining shallow enough to hide.
Depth Comparison (20ft Span)
Diagram for illustrative purposes only.
02. When to Choose LVL
Choose LVL beams when:
- Span is under 14 feet
- Budget is the primary concern
- A dropped bulkhead is acceptable
- Moisture exposure is low
- Easier installation is needed
Deflection Control
Wood is naturally flexible. Over time, heavily loaded wood beams can "creep" or sag permanently. Steel maintains its rigidity indefinitely.
Consistency
Engineered wood can vary slightly based on manufacturing batches. Steel is manufactured to exact metallurgical standards with zero variation.
Connection Strength
Steel connections are welded or bolted with high-tensile hardware, creating a unified structural frame that is superior to nailed wood connections.
03. Cost Comparison
Quick Answer:For spans under 12 feet, LVL is often sufficient and cheaper. For anything over 15 feet, steel is the standard for a reason.
While steel material costs are higher, the flush beam look adds immense value to a home. A flat ceiling makes a room feel larger and more luxurious compared to a room broken up by bulkheads covering large wood beams.
Steel W-Beam
| Span | Typical Cost |
|---|---|
| 12 ft | $2,500 – $3,500 |
| 16 ft | $4,000 – $6,000 |
| 20 ft | $6,000 – $9,000 |
| 24 ft | $9,000 – $14,000 |
LVL Beam
| Span | Typical Cost |
|---|---|
| 10 ft | $1,000 – $2,000 |
| 14 ft | $2,000 – $3,500 |
| 16 ft | $3,000 – $5,000 |
Worried about old beams? Wood beams naturally sag over 50+ years. If your floors are bouncy or sloping, check out our guide on the Top 5 Signs of Structural Fatigue.
04. Fire Safety Considerations
Steel Beams
Steel beams won't buckle in fire conditions. The Ontario Building Code recognizes this with lower fireproofing requirements, making steel the preferred structural solution in fire-sensitive applications.
LVL Beams
LVL beams will char and fail in fire. Additional fireproofing is required, which adds cost and complexity to the installation.
Important for semi-detached homes: Fire-rated separation is mandatory under the Ontario Building Code. Steel handles this requirement better than LVL, with fewer additional fireproofing measures needed.
05. Making Your Decision
Consider these five factors when choosing between steel and LVL:
- 1Span length — Determines feasibility. Steel is the only viable option over 14–16 feet.
- 2Aesthetic preference — Flush vs. bulkhead. Steel allows a flat, hidden ceiling; LVL usually requires a dropped bulkhead.
- 3Budget — Steel costs more upfront, but adds long-term value and avoids costly retrofits.
- 4Future plans — Consider long-term value and whether you plan to add loads above the beam.
- 5Home value — Steel adds more resale value with its cleaner finish and superior structural performance.
Frequently Asked Questions
Which beam type is stronger, Steel or LVL?
Steel beams are significantly stronger and stiffer than LVL beams, making them the only viable option for long spans (18ft+) or heavy loads in residential construction.
Can I use LVL for a flush beam installation?
It is often difficult. LVL beams require much more depth (height) than steel to carry the same load, which usually means they will hang down below the ceiling line rather than being hidden flush within the floor joists.
Is steel more expensive than LVL?
Yes, the material and installation cost of steel is higher due to weight and fabrication needs. However, the performance benefits and space-saving characteristics often justify the investment for open-concept renovations.
When should I choose LVL over steel?
LVL is a good choice when the span is under 14 feet, budget is a primary concern, a dropped bulkhead is acceptable, moisture exposure is low, and easier installation is needed.
How does fire resistance differ between steel and LVL?
Steel beams won't buckle in fire conditions, and the Ontario Building Code recognizes this with lower fireproofing requirements. LVL beams will char and fail in fire, requiring additional fireproofing. For semi-detached homes where fire-rated separation is mandatory, steel handles this better.
